1
//Set Up the 3DS Service - 3ds.service.tsx
2
import { Injectable } from '@angular/core';
3
import axios from 'axios';
4
5
export interface ChallengeData {
6
  transactionId: string;
7
  url: string;
8
  creq: string;
9
}
10
11
@Injectable({
12
  providedIn: 'root',
13
})
14
export class ThreeDsService {
15
  private apiUrl = 'https://api-sandbox.coinflow.cash/api/checkout/card/YOUR_MERCHANT_ID';
16
17
  constructor() {}
18
19
  // Get 3DS parameters
20
  get3DSParams() {
21
    return {
22
      colorDepth: window.screen.colorDepth,
23
      screenHeight: window.screen.height,
24
      screenWidth: window.screen.width,
25
      timeZone: -new Date().getTimezoneOffset(),
26
    };
27
  }
28
29
  // Initiates checkout and returns challenge data if 3DS is required
30
  initiateCheckout() {
31
    const data = {
32
      subtotal: { cents: 198 }, // Subtotal ending in 98 cents will force a 3ds challenge in sandbox
33
      authentication3DS: this.get3DSParams(),
34
      card: {
35
        cardToken: 'YOUR_CARD_TOKEN', // Use any valid tokenized card
36
        expYear: '29',
37
        expMonth: '10',
38
        email: 'dwaynejohnson@therock.com',
39
        firstName: 'Dwayne',
40
        lastName: 'Johnson',
41
        address1: '201 E Randolph St',
42
        city: 'Chicago',
43
        zip: '60601',
44
        state: 'IL',
45
        country: 'US',
46
      },
47
      saveCard: true,
48
    };
49
50
    return axios.post(this.apiUrl, data, {
51
      headers: {
52
        accept: 'application/json',
53
        'content-type': 'application/json',
54
        'x-coinflow-auth-session-key': 'PAYER_SESSION_KEY'
55
        // 'x-coinflow-auth-blockchain': 'PAYER_BLOCKCHAIN',
56
        // 'x-coinflow-auth-wallet': 'PAYER_WALLET_ADDRESS',
57
      },
58
    });
59
  }
60
61
  // Completes checkout after 3DS challenge
62
  completeCheckout(transactionId: string) {
63
    const data = {
64
      subtotal: { cents: 198 }, // Must match the subtotal from the initial request
65
      authentication3DS: { transactionId },
66
      card: {
67
        cardToken: 'YOUR_CARD_TOKEN', // Use any valid tokenized card
68
        expYear: '29',
69
        expMonth: '10',
70
        email: 'dwaynejohnson@therock.com',
71
        firstName: 'Dwayne',
72
        lastName: 'Johnson',
73
        address1: '201 E Randolph St',
74
        city: 'Chicago',
75
        zip: '60601',
76
        state: 'IL',
77
        country: 'US',
78
      },
79
      saveCard: true,
80
    };
81
82
    return axios.post(this.apiUrl, data, {
83
      headers: {
84
        accept: 'application/json',
85
        'content-type': 'application/json',
86
        'x-coinflow-auth-session-key': 'PAYER_SESSION_KEY'
87
        // 'x-coinflow-auth-blockchain': 'PAYER_BLOCKCHAIN',
88
        // 'x-coinflow-auth-wallet': 'PAYER_WALLET_ADDRESS',
89
      },
90
    });
91
  }
92
}
93
94
//Challenge Modal Component - challenge-modal.component.tsx
95
import { Component, Input, Output, EventEmitter, OnInit, OnDestroy } from '@angular/core';
96
import { CommonModule } from '@angular/common';
97
import { DomSanitizer, SafeResourceUrl } from '@angular/platform-browser';
98
99
@Component({
100
  selector: 'app-challenge-modal',
101
  standalone: true,
102
  imports: [CommonModule],
103
  templateUrl: './challenge-modal.component.html',
104
  styleUrls: ['./challenge-modal.component.css']
105
})
106
export class ChallengeModalComponent implements OnInit, OnDestroy {
107
  @Input() url: string | null = null;
108
  @Input() creq: string | null = null;
109
  @Input() transactionId: string | null = null;
110
  @Output() closeModal = new EventEmitter<void>();
111
  @Output() challengeComplete = new EventEmitter<string>();
112
113
  error: string | null = null;
114
  iframeSrc: SafeResourceUrl | null = null;
115
116
  constructor(private sanitizer: DomSanitizer) {}
117
118
  ngOnInit(): void {
119
    if (!this.url || !this.creq || !this.transactionId) {
120
      this.error = 'Missing data for challenge modal!';
121
      return;
122
    }
123
124
    // Sanitize the iframe url
125
    this.iframeSrc = this.sanitizer.bypassSecurityTrustResourceUrl(this.getIframeSrc());
126
127
    const handleMessage = (event: MessageEvent<string>) => {
128
      if (event.data === 'challenge_success') {
129
        this.challengeComplete.emit(this.transactionId!);
130
      }
131
    };
132
133
    window.addEventListener('message', handleMessage);
134
    this.ngOnDestroy = () => {
135
      window.removeEventListener('message', handleMessage);
136
    };
137
  }
138
139
  ngOnDestroy(): void {}
140
141
  onCloseModal() {
142
    this.closeModal.emit();
143
  }
144
145
  getIframeSrc(): string {
146
    const htmlContent = `
147
      <html>
148
        <body onload="document.challenge.submit()">
149
          <form method="post" name="challenge" action="${this.url}">
150
            <input type="hidden" name="creq" value="${this.creq}" />
151
          </form>
152
        </body>
153
      </html>
154
    `;
155
    const encodedHtml = encodeURIComponent(htmlContent);
156
    return 'data:text/html;charset=utf-8,' + encodedHtml;
157
  }
158
}
159
160
161
//Challenge Modal Template - challenge-modal.component.html
162
<div class="challenge-modal">
163
  <iframe
164
    *ngIf="iframeSrc"
165
    [src]="iframeSrc"
166
    style="width: 100%; height: 100vh; border: none;"
167
  ></iframe>
168
  <button (click)="closeModal.emit()">Close</button>
169
</div>
170
171
172
//Implement on Main App Component - app.component.tsx
173
import { Component, OnInit } from '@angular/core';
174
import { ThreeDsService } from './services/3ds.service';
175
import { ChallengeModalComponent } from './components/challenge-modal/challenge-modal.component';
176
import { CommonModule } from '@angular/common';
177
178
@Component({
179
  selector: 'app-root',
180
  standalone: true,
181
  imports: [CommonModule, ChallengeModalComponent],
182
  templateUrl: './app.component.html',
183
  styleUrls: ['./app.component.css']
184
})
185
export class AppComponent implements OnInit {
186
  challengeData = {
187
    url: '',
188
    creq: '',
189
    transactionId: ''
190
  };
191
  showChallengeModal = false;
192
193
  constructor(private threeDsService: ThreeDsService) {}
194
195
  ngOnInit(): void {
196
    this.initiateCheckout();
197
  }
198
199
  initiateCheckout() {
200
    this.threeDsService.initiateCheckout().then((response: any) => {
201
      if (response && response.data) {
202
        console.log('Checkout success!', response.data);
203
      }
204
    }).catch((error) => {
205
      console.error('Error during checkout initiation:', error);
206
      // handles 3ds challenge requirement
207
      if (error.response && error.response.status === 412) {
208
        const { transactionId, creq, url } = error.response.data;
209
        this.challengeData = { transactionId, creq, url };
210
        this.showChallengeModal = true;
211
      } else {
212
        console.error('Error', error);
213
      }
214
    });
215
  }
216
217
  handleChallengeComplete(transactionId: string) {
218
    console.log('challenge transaction id', transactionId);
219
    // completet checkout w/ transaction id after challenge is complete
220
    this.threeDsService.completeCheckout(transactionId)
221
      .then(response => {
222
        console.log('success', response);
223
        this.challengeData = { url: '', creq: '', transactionId: '' };
224
        this.showChallengeModal = false;
225
      })
226
      .catch(error => {
227
        console.error('error', error);
228
      });
229
  }
230
231
  closeModal() {
232
    this.showChallengeModal = false;
233
  }
234
}
235
236
237
//Add the App HTML Template - app.component.html
238
<app-challenge-modal
239
  *ngIf="showChallengeModal"
240
  [url]="challengeData.url"
241
  [creq]="challengeData.creq"
242
  [transactionId]="challengeData.transactionId"
243
  (challengeComplete)="handleChallengeComplete($event)"
244
  (closeModal)="closeModal()">
245
</app-challenge-modal>
